Pacific Capacitor Co.

Satisfying global high voltage capacitor needs since 1967

Powering real world applications as seen below

  • Design

    Fit, form, and function.

    Let us design to your specific, unique requirements.

  • Delivery

    Weeks, not months.

    As little as 2 week delivery.

  • Durability

    and performance

    Quality, reliability, long life.

    Suite of testing options:

    burn-in, corona, insulation resistance at rated voltage and max temperature.

Aerospace /

Defense

Communications

Medical

Laser

We take pride in our

Type SM High Voltage Mica Capacitor

The type SM capacitor is a high voltage dielectric device that incorporates the excellent electrical characteristics of a fabricated mica dielectric with a resin impregnation to achieve exceptional reliability at temperatures in excess of 150° C.  The standard type SM is housed in a polyester tape wrap with epoxy end seals.  The standard unit is supplied with #18 or #20 AWG tinned copper axial wire leads.

Electrical Specifications

Performance Characteristics



Capacitance Range



Capacitance Tolerance



Working Voltage



Temperature Range



Insulation Resistance









Dielectric Withstand Voltage





0.0001 to 1.0 µF @ 1000Hz @ 25°C



± 10% @ 1000Hz @ 25°C



1,000 to 100,000 VDC



-65 to +125°C and 150°C with voltage derating



Temperature        MΩ µF                   Need not Exceed



@ + 25°C             5,000 MΩ µF         100,000 MΩ µF

@ + 125°C           1.5 MΩ µF             1,500 MΩ µF



150% rated WVDC



Click here to

View Available Dimensions

Type RM High Voltage DC Filter Capacitor

The type RM capacitor is an intermediate high voltage device that incorporates the excellent electrical characteristics of a fixed kraft paper and polyester dielectric with a resin impregnation to achieve exceptional reliability in the smallest possible size.  The standard type RM is made with either a non-inductive (extended foil) construction or a multiple tab construction, and is housed in a polyester tape wrap with epoxy end seals.  The standard unit is supplied with #18 or #20 AWG tinned copper axial wire leads.



Capacitance Range



Capacitance Tolerance



Working Voltage



Temperature Range



Insulation Resistance









Dielectric Withstand Voltage





0.0001 to 1.0 µF @ 1000Hz @ 25°C



± 10% @ 1000Hz @ 25°C



1,000 to 100,000 VDC



-40 to +85°C and 150°C with voltage derating



Temperature        MΩ µF                   Need not Exceed



@ + 25°C             10,000 MΩ µF      10,000 MΩ µF

@ + 85°C             300 MΩ µF            2,000 MΩ µF



150% rated WVDC



Click here to

View Available Dimensions

Electrical Specifications

Performance Characteristics

Company Profile

Pacific Capacitor Co. has been providing high quality products and responsive customer service to high voltage users throughout the globe since 1967.  Product developments have allowed Pac-Cap to respond quickly and effectively to changing customer demands.

Facilities and Equipment



Our uniquely designed processing technology allows us to develop state of the art components that are smaller and higher performance than the industry standard.



Our Mission



To provide individualized solutions to each of our customers' unique high voltage needs, in a timely manner, with the highest quality products available.



Our facility is located in Morgan Hill, California which is

20 miles south east of downtown San Jose and

23 miles north east of the coastal community of Santa Cruz.

We encourage both prospective and existing customers

to visit our facility as seen below.
